ZD 系列渣漿泵(單泵殼)

主要技術(shù)參數(shù)The main technical parameters
口徑（Diameter）:25~300 mm
流量（Flow）:10~1300 m3/h
揚程（Head）: 10~70 m
溫度（Temperature）: -20~+100℃
比重（S.G）：≤1.8

應用范圍 Application Scope
該系列泵主要針對電力、冶金、煤炭，建材等行業(yè)中輸送中性或堿性含有顆粒的漿料，作為電廠脫硫用漿液泵，其固液混合物的濃度常為：灰漿20%，礦漿30%。
This series of pumps are mainly used for conveying neutral or alkaline slurries containing particles in the power,
metallurgy, coal, building materials and other industries. As a slurry pump for desulfurization in power plants, the
concentration of the solid-liquid mixture is usually: 20% for ash slurry and 30% for ore slurry。
